J9500 Stainless Steel Grade 13 Ball Bearing Hinge – handles&hinges

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

J9500 Stainless Steel Grade 13 Ball Bearing Hinge

Stainless Steel Grade 202
Dim. 102 x 76 x 3mm
Radius/Square
Grade 13
Max. 120kg Doors with 3 hinges
EN 1935:2002, Grade 13
FD30/FD 60 with Intumescent hinge pad
Fire Cert CF547
200,000 cycles – Grade 4 corrosion
FD30, All hinges must be bedded onto 1mm thickness of mono ammonium phosphate or graphite based intumescent sheet material behind both blades.
FD60, All hinges must be bedded onto 2mm thickness of mono ammonium phosphate or graphite based intumescent sheet material behind both blades.
